Piston rod hardness testing: Hardness tester measurement is usually divided into two types: destructive measurement and non-destructive measurement. Non destructive measurement has less damage and cannot achieve complete non damage. Compared to the shaft in the middle of the piston, this injury is fatal, so only destructive measurement methods can be used.
Customs code for piston rod: 84129090.00 oil cylinder piston rod, 84129090.90 oil cylinder piston rod, 84129090.90 high-precision oil cylinder piston rod, 84314990 horizontal oil cylinder piston rod, 84314990 variable amplitude oil cylinder piston rod, 84799090 oil cylinder piston rod.
Manufacturing process
Outer diameter of 20-500mm, length of 600-15000mm, precision slender shaft and piston rod. We use professional processes such as precision cold drawing, precision grinding, and high-precision polishing to manufacture, and all technical indicators meet national standards.
Design of Piston Rods
1. The purpose of the equipment and the conditions of the workpiece.
2. The structural characteristics, load conditions, required speed, size stroke, and action requirements of the working organization.
3. The selected hydraulic system working pressure.
4. The current status of materials, accessories, and processing techniques.
5. Relevant national standards and technical specifications, etc.
6. Efforts should be made to ensure that the piston rod can withstand very large loads in a high load state, and has good longitudinal stability in a high pressure state.
Applications of Piston Rods
This product can be directly used in industries with precision slender shafts as components, such as oil cylinders, air cylinders, shock absorbers, textile printing and dyeing, printing machinery guide rods, die-casting machines, injection molding machine guide rods and top rods, four column press guide columns, fax machines, printers and other modern office machinery guide shafts.
Dimensional tolerance table
|
Allowable difference level |
Level 7 (h7) |
Level 8 (h8) |
Level 9 (h9) |
Level 10 (h10) |
Level 11 (h11) |
F7 level (F7) |
F8 level (f8) |
|
Diameter m/m |
|
6-10 |
0-0.015 |
0-0.022 |
0-0.036 |
0-0.058 |
0-0.09 |
-0.013-0.028 |
-0.013-0.035 |
|
10-18 |
0-0.018 |
0-0.027 |
0-0.043 |
0-0.058 |
0-0.09 |
-0.016-0.034 |
-0.016-0.043 |
|
18-30 |
0-0.021 |
0-0.033 |
0-0.052 |
0-0.084 |
0-0.13 |
-0.02-0.041 |
-0.02-0.053 |
|
30-50 |
0-0.025 |
0-0.039 |
0-0.062 |
0-0.1 |
0-0.16 |
-0.025-0.05 |
-0.025-0.064 |
|
50-80 |
0-0.030 |
0-0.046 |
0-0.074 |
0-0.12 |
0-0.19 |
-0.03-0.06 |
-0.03-0.076 |
|
80-120 |
0-0.035 |
0-0.054 |
0-0.087 |
0-0.14 |
0-0.22 |
-0.036-0.071 |
-0.036-0.9 |
Piston Rod is a high-precision hydraulic component manufactured by Wuxi Xinluo Hydraulic Machinery in China. We specialize in producing piston rod with strict quality control and precision processing for industrial hydraulic applications.
We manufacture high quality custom piston rods for hydraulic cylinders in various materials including carbon steel, alloy steel and stainless steel, with hard chrome plating for excellent wear resistance. Each piston rod is precision processed and inspected to ensure it meets your specifications.
Key Facts
-
Manufactured by Wuxi Xinluo Hydraulic with 20+ years of experience
-
ISO 9001 quality certified production process
-
Custom sizes and specifications available
-
Precision grinding and honing processes
-
Strict dimensional tolerance control
-
Export quality standards
Frequently Asked Questions
What is piston rod?
Piston Rod is a precision hydraulic component used in industrial machinery and hydraulic systems. Wuxi Xinluo Hydraulic manufactures high quality piston rod with strict quality control to meet industrial application requirements.
What is piston rod used for?
Piston Rod is used in hydraulic and pneumatic systems to provide mechanical movement, pressure containment or guidance in industrial machinery, automation, and manufacturing equipment.
Can you custom manufacture piston rod?
Yes, Wuxi Xinluo Hydraulic offers custom manufacturing of Piston Rod according to your specific dimensions, materials and technical requirements.
